Technische Spezifikationen
- Rahmenset
- SWAT™
- SWAT 4.0 internal downtube storage
- Rahmen
- FACT 11m carbon chassis, rear-end, and link, Trail Geometry, SWAT™ Door integration, head tube angle adjustment, threaded BB, internal brake and dropper cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 145mm of travel
- Sattelklemme
- Alloy, 38.6mm
- Fahrwerk
- Gabel
- FOX FLOAT 36 Factory, GRIP X2 damper, HS and LS rebound and compression adjustment, 15x110mm QR axle, 44mm offset, S1:140mm of travel, S2-S6:150mm of travel
- Dämpfer
- FOX FLOAT Factory with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever w/3 setting Open mode tuning range, LSR adjustment, S1:210×52.5mm, S2-S6:210x55mm
- Bremsen
- Vorderradbremse
- SRAM Maven Ultimate, 4-piston caliper, hydraulic disc, 200mm HS2 Rotor
- Hinterradbremse
- SRAM Maven Ultimate, 4-piston caliper, hydraulic disc, S1-S2: 180mm, S3-S6: 200mm HS2 Rotor
- Antrieb
- Kassette
- SRAM XX Eagle SL Transmission Cassette, 12spd, 10-52t
- Tretlager
- SRAM DUB, BSA 73mm Wide, Threaded
- Schalthebel
- SRAM AXS POD Ultimate Controller
- Kurbelgarnitur
- SRAM XX Eagle Crankset, 32T ring, Integrated Guard, 55mm Chainline, S1-S3:165mm, S4-S6: 170mm
- Schaltwerk
- SRAM XX Eagle Transmission Derailleur
- Kette
- SRAM XX Eagle SL Transmission Flattop Chain
- Laufräder
- Felgen
- Roval Traverse SL II, hookless carbon, 30mm inner width, tubeless ready, 28h, Front: 29, Rear: S1-S2: 27.5, S3- S6: 29
- Vorderradnabe
- DT Swiss 240, 15x110mm, 28h
- Vorderreifen
- Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29×2.3″
- Hinterradnabe
- DT Swiss 240, 12x148mm, 28h
- Hinterreifen
- Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, S1-S2: 27.5×2.3, S3- S6: 29×2.3″
- Speichen
- DT Swiss Aerolite
- Schläuche
- Standard, Presta valve
- Cockpit
- Vorbau
- Deity, 35mm clamp, 35mm length
- Lenkergriffe
- Deity Lockjaw
- Lenker
- Roval Traverse SL Carbon, riser bar, 6-degree upsweep, 8-degree backsweep, 30mm rise, S1-S2: 780mm: S3-S6: 800mm
- Sattelstütze
- RockShox, Reverb AXS, 30.9, S1: 125mm, S2: 150mm, S3-S6: 170mm
- Sattel
- Power Pro Mirror, Hollow Ti rails, S1-S2: 155mm, S3-S6: 143mm
- Gewicht
- Gewicht
- 13.56kg (29 lb, 14.3 oz)
- Produkt-ID
- 221406
- Gemessene Rahmengröße
- S4
