Details
Plattform
Scalpel
Modell
Scalpel Hi-MOD Ultimate
Modellnummer
C24102M
Rahmenset
Rahmen
Scalpel Hi-Mod Carbon, 100mm travel, Proportional Response Tuned, FlexPivot Chainstay, PF30-83, Tapered Headtube, Speed Release 12mm thru axle, 55mm chainline, Stash compatible
Gabel
Lefty Ocho Carbon, 100mm, Chamber Damper with remote lockout, OppO Spring System, tapered steerer, 55mm offset
Steuersatz
Integrated Sealed Bearing, Tapered
Rear Shock
Fox Float DPS Factory EVOL, 100mm, remote lockout, adjustable rebound
Antrieb
Schaltwerk
SRAM XX1 Eagle AXS
Schalthebel
SRAM Eagle AXS, 12-speed
Kette
SRAM XX1 Eagle, Rainbow, 12-speed
Kurbel
SRAM XX1 Eagle DUB, 34T, 55mm chainline
Kassette
SRAM XG-1299, XX1 Eagle, Rainbow, 10-52, 12-speed
Bottom Bracket
SRAM DUB PF30 MTB83
Bremsen
Bremsen
SRAM Level Ultimate hydraulic disc, 160/160mm CenterLine X rotors
Bremshebel
SRAM Level Ultimate hydraulic disc
Laufräder
Felgen
HollowGram XC-S 27, Lightweight, Hi-Impact Carbon, 27mm IW, 28h, tubeless ready
Speichen
DT Swiss Competition Race, straight-pull
Reifen
(F) Schwalbe Racing Ray EVO, 29 x 2.25″, SnakeSkin, Addix Speedgrip, tubeless ready, (R) Schwalbe Racing Ralph EVO, 29 x 2.25″, SnakeSkin, Addix Speed, tubeless ready
Reifengröße
2.35
Reifendimension
29
Naben
(F) HollowGram Lefty 60 / (R) HollowGram w/DT Swiss 350 Star Ratchet internals, 12x148mm thru-axle
Vorderreifen
Schwalbe Racing Ray EVO, 29 x 2.25″, SnakeSkin, Addix Speedgrip, tubeless ready
Hinterreifen
Schwalbe Racing Ralph EVO, 29 x 2.25″, SnakeSkin, Addix Speed, tubeless ready
Komponenten
Lenker
Cannondale 1 Flat, Carbon, 31.8mm, 9° back, 760mm
Vorbau
Cannondale 1, 7075 Alloy, 1-1/8″, 31.8, 7°
Griffe
Cannondale XC Silicone
Sattel
Prologo Dimension NDR, Tirox rails
Sattelstütze
Cannondale 1, UD Carbon, 31.6 x 400mm
Verbindung
Radsensoren
Cannondale Wheel Sensor
