Rahmen
Rahmen
Aluminium Superlite, Gravity Casting, Agile Ride Geometry, 1.5 Headtube, Boost 148, Fully Integrated Battery, Advanced Internal Cable Routing, Kickstand/Fender/Carrier Mounting Points
Größe
Size Split: 27.5: S (15″) // 29″: M (17″), L (19″), XL (21″), XXL (23″); Easy Entry: 27.5: S (16″), M (18″), L (20″), XL (22″)
Fahrwerk
Federgabel
Fox 34 Float AWL, 2-Position Sweep-Adjust RAIL Damper, Tapered, 15x110mm, E-Bike Optimized, 120mm (EE: 100mm)
E-Bike System
Motor
Bosch Drive Unit Performance CX Generation 4 (85Nm) Cruise (250Watt), Smart System
Remote
Bosch LED Remote
Akku
Bosch PowerTube 750
Display
Bosch Kiox 300
Ladegerät
Bosch 4A
Antrieb & Bremse
Bremsanlage
Sram DB8, Hydr. Disc Brake (200/200)
Schaltwerk
Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed
Schalthebel
Shimano Deore SL-M6100-IR, Direct Attach, Rapidfire-Plus
Kurbelgarnitur
ACID E-Crank, 38T, 175mm
Kassette
Shimano Deore CS-M6100, 10-51T
Kette
Shimano CN-M6100
Cockpit
Steuersatz
ACROS AZF-1035, ICR (Integrated Cable Routing), BlockLock 120°, Top Zero-Stack 1 1/2″ (ZS 56mm), Bottom Zero-Stack 1 1/2″ (ZS 56mm)
Vorbau
CUBE Performance Stem E-MTB, 31.8mm
Lenker
CUBE Rise Trail Bar Pro, 740mm
Griffe
ACID React Pro / EE: ACID Hybrid Perform
Laufräder
Felgen
CUBE EX30, 32H, Disc, Tubeless Ready
Vorderrad Nabe
Shimano HB-MT400-B, 15mm, Boost, Centerlock
Hinterrad Nabe
Shimano FH-MT410-B, 12mm, Boost, Centerlock
Reifen
Schwalbe Smart Sam, Performance, Double Defense, 2.6, Next Gen
Ausstattung
Sattel
Natural Fit Sequence
Sattelstütze
CUBE Performance Post, 30.9mm
Pedale
ACID PP MTB
Artikelinformationen
Farbe
rubyred´n´black
Gewicht
24,5 kg
